Grundfos CRI 10 Vertical Multistage Pumps

View delivery information

Price match guarantee, call 0121 123 456 if you've seen it cheaper

Grundfos CRI 10 vertical multistage pumps are with the higher flow of the Grundfos CRI series. These multistage centrifugal pumps are renowned for their reliability and are typically used for industrial and commercial applications such as pressure boosting, boiler feeding, washing systems, water supply, water treatment systems and more.

22 options available from £1,261.60

Description

Downloads

Need help choosing? Send enquiry

Options Available

Model	SKU	Rrp	Motor	Maxhead	Maxflow	Voltage	Our Price (ex VAT)
CRI 10-1 230V	3912-169	£1,599.00	0.37 kW	10 m	216 l/min	51	£1,535.04 £1,279.20	Loading... Add to Basket
CRI 10-2 230V	3912-170	£1,737.00	0.75 kW	20 m	216 l/min	51	£1,667.52 £1,389.60	Loading... Add to Basket
CRI 10-3 230V	3912-171	£2,067.00	1.10 kW	31 m	216 l/min	51	£1,984.32 £1,653.60	Loading... Add to Basket
CRI 10-4 230V	3912-172	£2,352.00	1.50 kW	41 m	216 l/min	51	£2,257.92 £1,881.60	Loading... Add to Basket
CRI 10-5 230V	3912-173	£2,544.00	2.20 kW	51 m	216 l/min	51	£2,442.24 £2,035.20	Loading... Add to Basket
CRI 10-6 230V	3912-174	£2,662.00	2.20 kW	62 m	216 l/min	51	£2,555.52 £2,129.60	Loading... Add to Basket
CRI 10-1 400V	3912-175	£1,577.00	0.37 kW	10 m	216 l/min	53	£1,513.92 £1,261.60	Loading... Add to Basket
CRI 10-2 400V	3912-176	£1,636.00	0.75 kW	20 m	216 l/min	53	£1,570.56 £1,308.80	Loading... Add to Basket
CRI 10-3 400V	3912-177	£1,886.00	1.10 kW	31 m	216 l/min	53	£1,810.56 £1,508.80	Loading... Add to Basket
CRI 10-4 400V	3912-178	£2,098.00	1.50 kW	41 m	216 l/min	53	£2,014.08 £1,678.40	Loading... Add to Basket
CRI 10-5 400V	3912-179	£2,271.00	2.20 kW	51 m	216 l/min	53	£2,180.16 £1,816.80	Loading... Add to Basket
CRI 10-6 400V	3912-180	£2,389.00	2.20 kW	62 m	216 l/min	53	£2,293.44 £1,911.20	Loading... Add to Basket
CRI 10-7 400V	3912-181	£2,580.00	3.00 kW	72 m	216 l/min	53	£2,476.80 £2,064.00	Loading... Add to Basket
CRI 10-8 400V	3912-182	£2,693.00	3.00 kW	82 m	216 l/min	53	£2,585.28 £2,154.40	Loading... Add to Basket
CRI 10-9 400V	3912-183	£2,807.00	3.00 kW	92 m	216 l/min	53	£2,694.72 £2,245.60	Loading... Add to Basket
CRI 10-10 400V	3912-184	£3,318.00	4.00 kW	103 m	216 l/min	53	£3,185.28 £2,654.40	Loading... Add to Basket
CRI 10-12 400V	3912-185	£3,545.00	4.00 kW	123 m	216 l/min	53	£3,403.20 £2,836.00	Loading... Add to Basket
CRI 10-14 400V	3912-186	£4,114.00	5.50 kW	143 m	216 l/min	53	£3,949.44 £3,291.20	Loading... Add to Basket
CRI 10-16 400V	3912-187	£4,345.00	5.50 kW	164 m	216 l/min	53	£4,171.20 £3,476.00	Loading... Add to Basket
CRI 10-18 400V	3912-188	£4,757.00	7.50 kW	185 m	216 l/min	53	£4,566.72 £3,805.60	Loading... Add to Basket
CRI 10-20 400V	3912-189	£4,981.00	7.50 kW	206 m	216 l/min	53	£4,781.76 £3,984.80	Loading... Add to Basket
CRI 10-22 400V	3912-190	£5,208.00	7.50 kW	226 m	216 l/min	53	£4,999.68 £4,166.40	Loading... Add to Basket

Description

Grundfos CRI 10 vertical multistage centrifugal pumps are high flow (216 l/min) models of the Grundfos CRI series. Suitable for pressure boosting, boiler feeding, washing systems, water supply, water treatment systems, cooling and air conditioning and firefighting, these Grundfos multistage pumps are ideal for a range of high-pressure industrial and commercial applications. These multistage water pumps are designed for transferring clean and low-viscosity fluids and are renowned for their reliability and high quality. Carefully designed to provide optimal performance in extreme conditions, the CRI10 vertical multistage pumps are a great solution for operations requiring heavy-duty pumps for long operating hours and frequent interruptions.

Made of AISI 304 grade stainless steel, these Grundfos multistage centrifugal pumps have a compact design ideal for installations with limited space. These vertical multistage centrifugal pumps have a state-of-the-art hydraulic design for maximised efficiency and are supplied with an enhanced impeller design to ensure a more streamlined flow and reduced friction loss. To further enhance the pump design, the CRI1 multistage pumps are equipped with unique features such as dry-running protection, a unique cartridge seal that enables easy service and a highly efficient and silent EFF1 motor. These Grundfos multistage pumps also come with stainless steel pump bases and durable bearings available in a wide range of options for difficult liquids.

The CRI 10 multistage water pumps are versatile solutions in 3 different material executions, including titanium, AISI 316 stainless steel and stainless steel with cast iron. As a Grundfos pump supplier, we can also provide these multistage centrifugal pumps in different modular configurations to cope with high pressures, high temperatures, and very aggressive, corrosive or dangerous liquids.

Specifications
►Maximum liquid temperature: 120ºC

Materials
►AISI 304 Stainless steel construction

Please note: CRI pumps are supplied without pipe connections. Two bolt oval pipe flanges and DIN counter flanges must be ordered separately. See link at the bottom of this page.

WRAS Approved

Whisper Pumps have been supplying Grundfos pumps for over 25 years, meaning we are highly experienced in all models and our team have expert product knowledge. If you are unsure about the multistage water pump model you require, please contact our technical sales team today on 01777 871100 for free, expert advice.
